Multifunction I/O

Multifunction I/O products combine common I/O, including analog input and output and counter/timer functionality, into a single form factor to help reduce complexity and meet multiple system requirements.

Multifuction I/O equipment

Multifunction DAQ Functionality with Common Form Factors

Multifunction I/O hardware includes options for a large variety of channel combinations and form factors, including USB, PCI, and PCI Express. With this variety you can choose the hardware that can handle all the signal types you need.

Reconfigurable I/O Options

Reconfigurable multifunction I/O products offer advanced functionality, such as multirate sampling and individual channel triggering, because of the onboard FPGA. You can customize these models with the LabVIEW FPGA Module.

PLATFORM MODULES

Platform modules integrate with modular hardware platforms that allow you to combine different types of modules in a custom system that leverages shared platform features. NI offers three hardware platforms—CompactDAQ, CompactRIO, and PXI—though all platforms may not be represented in this category.

PXI FlexRIO Muntifunction IO Module.png

PXI FlexRIO Multifunction I/O Module

Supports multiple traction motor models for signal level inverter hardware-in-the-loop (HIL) applications.

TestScale Analog Output Module

TestScale Analog Output Module

Provides a mix of analog I/O, digital I/O, counter/timer, and triggering functionality in a single PXI module.
Feature Highlights:

Platform: PXI
Bus: PXI, PXI Express

TestScale Analog Input Module

TestScale Analog Input Module

Provides combinations of analog I/O and digital I/O in a single PXI module with a user-programmable FPGA for onboard signal processing and custom system timing and synchronization.
Feature Highlights:

Platform: PXI
Bus: PXI, PXI Express

C Series Multifunction I/O Module

C Series Multifunction I/O Module

Combines common I/O circuitry, including analog and digital I/O, into a single module for CompactRIO systems.
Feature Highlights:

Platform: CompactRIO

PXI Multifunction IO Bundle.png

PXI Multifunction I/O Bundle

The PXI Multifunction I/O Bundle includes a chassis with a PXI Multifunction I/O Module to help you test electronic devices.

TestScale Analog Input Module.png

TestScale Analog Input Module

Provides analog input voltage signal measurement capabilities for electrical functional test applications.
Feature Highlights:

Platform: TestScale

TestScale Power Module.png

TestScale Power Module

The Benchtop Measurement Bundle with Multifunction I/O Hardware includes a PXI Chassis, PXI Multifunction I/O Module, and more.

TestScale Digital IO Module.png

TestScale Digital I/O Module

Provides bidirectional digital voltage signal capabilities for electrical functional test applications.
Feature Highlights:

Platform: TestScale

TestScale Analog Output Module.png

TestScale Analog Output Module

Provides analog output voltage signal generation capabilities for electrical functional test applications.
Feature Highlights:

Platform: TestScale

TestScale Backplane.png

TestScale Backplane

Features USB connectivity and includes five slots that you can use to add I/O or power modules to your TestScale system.
Feature Highlights:

Platform: TestScale


TestScale Digital Output Module.png

TestScale Digital Output Module

Provides digital output voltage signal generation capabilities for electrical functional test applications.
Feature Highlights:

Platform: TestScale

STAND-ALONE OR COMPUTER-BASED DEVICES

Stand-alone or computer-based devices either integrate with standard desktop and laptop computers or allow you to use them without the need for other modular hardware.

Multifunction IO Device.png

Multifunction I/O Device

Provides combinations of analog I/O, digital I/O, and counter/timer functionality in a single device for computer-based systems.
Feature Highlights:

Bus: PCI, PCI Express, USB

Multifunction Reconfigurable IO Device.png

Multifunction Reconfigurable I/O Device

Controls I/O signals and provides a user-programmable FPGA for onboard signal processing and flexible system timing and synchronization.
Feature Highlights:

Bus: PCI Express, USB
